The NS Bikes RNS is a rugged fork built for street and flat track riding—without compromise. Its unique, short-travel geometry (28mm) and robust, hardened 4130 Cr-Mo steel construction make it the perfect choice for riders who take their bike to the limit every day. Compatible with street and fixed-gear bikes, the RNS fork combines style and durability.

Product features:
✔ Intended use: street / flat / fixie
✔ Triple butted Cr-Mo 4130 tubes
✔ One-piece CNC steerer tube + 7075 aluminum cap
✔ 28mm trail – easier nose manuals and more control
✔ Compatible with 26” wheels and 9/10 mm axles

Technical specifications:
🔹 Material: Cr-Mo 4130, hardened steel
🔹 Fork height: 430 mm
🔹 Trail: 28 mm
🔹 Steerer tube: 170mm, integrated, IS (M24x1.5" thread)
🔹 Cap: 7075 aluminum, 6/8 mm hexagon socket
🔹 Hooks: 6 mm, with locking washer
🔹 Compatibility: MTB/BMX 100mm hubs, 9mm/10mm axle
🔹 Brakes: no pivots
🔹 Weight: approx. 1.39 kg + 0.03 kg cap

For whom:
🔸 For advanced street/park riders
🔸 For fixed gear users looking for a solid fork
🔸 For those building a Capital or fixed gear bike

The most important advantages:
✅ Low weight and high stiffness thanks to advanced processing
✅ Aggressive geometry perfect for street and technical tricks
✅ Compatibility with classic axles and integrated system
✅ Anti-corrosion protection – internal and external galvanization
✅ Stylish, minimalist design with BMX roots

🛠️ The perfect duo with the NS Capital frame – for riders who refuse to compromise!
